CTO-3600AX BRAKE DRUM (REAR, 16.50" X 7")
Couldn't load pickup availability
- Fully secure checkout
- Trusted by thousands
- Rated and reviewed
Shop safely
Secure your shopping experience with various safe and trusted payment methods.
Technical Specifications
| Part Type | Brake Drum (Standard Duty) |
|---|---|
| Industry Number | 3600AX (Balanced) / Webb 66864 |
| Brake Size | 16.5" x 7" (Friction Surface) |
| Mounting Type | Outboard / Hub Pilot (Unimount) |
| Bolt Holes | 10 Holes |
| Bolt Circle | 11.25" |
| Pilot Hole | 8.78" (Critical for Hub Pilot) |
| Overall Depth | 10.62" (Approx) |
| Weight | 100 - 108 lbs (Standard) |
Cross References
| Brand | Part Number |
|---|---|
| CTO | CTO-3600AX |
| Automann | 145.3600AX |
| ConMet | 10009830, 107507 |
| Durabrake | 3600AX |
| Fleetrite | FLT3600AX |
| Gunite (Accuride) | 3600A, 3600AX |
| KIC | 60001 |
| Meritor | 85-123207, 03-123207 |
| Webb Wheel | 66864 (Current Official), 3600A |
Compatibility & Selection Guide
| Compatible Brake Shoes | |
|---|---|
| 4707 (Meritor Q Plus) - Most common pairing. 4709 / 4709ES2 (Eaton 16.5x7). 4515 (Meritor Standard 16.5x7). 4311 (Eaton Single Anchor). * NOT for 4711/4726 (Too wide) or 4720/4715 (Too narrow). | |
| Standard (3600AX) vs. Heavy Duty (3687) | |
| 3600AX (This Part) Weight: ~105 lbs Application: Standard Highway / OTR. Most popular general purpose drum. | 3687 (Webb 66884) Weight: ~120 lbs Application: Heavy Haul, Dump Trucks, Refuse. Thicker metal for better heat dissipation. |
