T211NS OIL DRAIN PLUG VALVE NIPPLE OIL DRAIN VALVE WITH M27-2.0

Low stock
$51.99
$51.99
  • Fully secure checkout
  • Trusted by thousands
  • Rated and reviewed

Technical Specifications

Feature Details / Value
Thread Size M27-2.0 (27mm Diameter / 2.0mm Pitch)
Nipple Dimensions Diameter: 5/8" (15mm) | Length: 5/8" (15mm) [Short Nipple Type]
Body Material Forged Brass
Internal Materials Stainless Steel Handle & Spring | Chrome Plated Brass Ball
Pressure & Temperature Pressure Rating: 145 PSI | Temperature Range: -40° to 365° F (-40° to 185° C)
Recommended Torque 531 in-lbs / 44 ft-lbs (60 Nm)
Sealing Type Blue Fiber Gasket (27mm Fiber Gasket)
Factory Pressure Tests Hydraulic Test Pressure: 0.6 MPa | Leakage Test Pressure: 0.10 MPa
Weight 0.47 lbs (213 g)

Cross References & Accessories

Brand / Category Part Number / Model
Fumoto (Main Product) T211NS
AutoZone SKU Number 1407540
Clear Vinyl Tubing Hose M-Hose (5/8" Inside Diameter Hose)
Large Lever Clip LC-20 (For FG, T, and SX industrial series valves)
Lever Lock T-Lock (For FG & T series valves)
Replacement Gasket Washer G-27 (M27 Fiber Gasket - Not compatible with SX valves)
L-Shaped Socket SL-15 (For valves with 5/8" nipples)

Applications & Installation Guide

Category Instructions & Guidelines
Recommended Use • Recommended for use on industrial engines, fleet semi-trucks, and commercial vehicles with high ground clearance. • Warning: NOT RECOMMENDED FOR PASSENGER VEHICLES WITH LOW GROUND CLEARANCE due to the integrated nipple design. • Preferred and trusted worldwide across various commercial industries, including manufacturers like Caterpillar, Cummins, Daimler, Freightliner, Kenworth, Paccar, Peterbilt, Volvo, and others.
Standard Installation 1. Prepare: Place the blue fiber gasket flat onto the valve base. Remove the original stock drain plug from the oil pan, drain the old engine oil completely, and clean the port area thoroughly before installing. 2. Mounting: Thread the valve into the drain port smoothly by hand to prevent cross-threading. Fully tighten using a crescent wrench directly on the valve body 1/8 to 1/4 turn past hand tight (or apply the specified 44 ft-lbs torque). Do not apply force or use tools on the head of the nipple outlet. 3. Close & Fill: Close the valve firmly by turning the control lever clockwise until it stops and is perpendicular to the oil outlet. The lever will click and lock completely into its safety recess slot. Install the safety lever clip and refill with new engine oil.
Operation • To Open: Remove the safety lever clip (if installed), lift the control lever firmly upward to unlock it from its safety recess, and turn it 90° counter-clockwise. • To Close: Turn the lever firmly clockwise until it stops and snaps on its own (clicking) completely into the safety retention recess slot (remaining perpendicular to the outlet). It should not be possible to rotate the lever without lifting it upward first. Re-install the safety clip.
